Specifications
| Model | LA04S | LA06S | LA10S |
|---|---|---|---|
| Pixel Configuration | SMD | SMD | SMD |
| Physical Pixel Pitch (mm) | 4.44 | 6.67 | 10 |
| Module Resolution (WxH) | 72×72 | 48×48 | 32×32 |
| Module Dimension (WxH, mm) | 320×320 | 320×320 | 320×320 |
| Module Composition (WxH) | Standard: 4×3 | Standard: 4×3 | Standard: 4×3 |
| Cabinet Resolution (WxH) | 288×216 | 192×144 | 128×96 |
| Cabinet Dimension (WxHxD, mm) | Standard: 1280x960x71 (Optional: 1280X640 / 960×960 / 960×640 / 640X960 / 640X640) | Standard: 1280x960x71 (Optional: 1280X640 / 960×960 / 960×640 / 640X960 / 640X640) | Standard: 1280x960x71 (Optional: 1280X640 / 960×960 / 960×640 / 640X960 / 640X640) |
| Cabinet Area (m²) | Standard: 1.2288 | Standard: 1.2288 | Standard: 1.2288 |
| Weight (kg/cabinet; kg/m²) | 35; 28 | 35; 28 | 35; 28 |
| Pixel Density (Point/m²) | 50625 | 22500 | 10000 |
| IP Level | IP65 Front/Rear | IP65 Front/Rear | IP65 Front/Rear |
| Brightness (nits) | 6000 | 7500 | 7500 |
| Color Temperature (K) | 3000-10000 | 3000-10000 | 3000-10000 |
| Viewing Angle (horiz; vert) ° | 150; 110 | 150; 110 | 150; 110 |
| Deviation of LED Luminance Center (after calibration) | <3% | <3% | <3% |
| Contrast Ratio | 6000:1 | 6000:1 | 6000:1 |
| Power Consumption(max; avg)/m² | 720W; 240W | 790W; 265W | 790W; 265W |
| Input Voltage (V) | AC100~240V（50-60Hz） | AC100~240V（50-60Hz） | AC100~240V（50-60Hz） |
| Installation | Front/Rear | Front/Rear | Front/Rear |
| Maintenance | Front/Rear access | Front/Rear access | Front/Rear access |
| Refresh Rate @60Hz | ≥3840 | ≥3840 | ≥3840 |
| Frame Rate Processing (Hz) | 50 & 60 | 50 & 60 | 50 & 60 |
| Operation Temperature (°C) | -30 to 60 | -30 to 60 | -30 to 60 |
| Storage Temperature (°C) | -40 to 60 | -40 to 60 | -40 to 60 |
| Operation Humidity (RH) | 10 – 90% | 10 – 90% | 10 – 90% |
| Storage Humidity (RH) | 10 – 80% | 10 – 80% | 10 – 80% |
