Specifications
| DLU-0.6 | DLU-0.7 | DLU-0.9 | DLU-1.2 | |
|---|---|---|---|---|
| Pixel Pitch (mm) | 0.625mm | 0.78125mm | 0.9375mm | 1.2mm |
| Cabinet Size (WxHxD) | 600 x 337.5 x 69 mm (23.6″ x 13.3″ x 2.7″) | 600 x 337.5 x 69 mm (23.6” x 13.3” x 2.7”) | 600 x 337.5 x 69 mm (23.6” x 13.3” x 2.7”) | 600 x 337.5 x 69 mm (23.6” x 13.3” x 2.7”) |
| Cabinet Resolution (WxH) | 960 x 540 | 768 x 432 | 640 x 360 | 480 x 270 |
| Pixel Density (pixel/m²) | 2560000 per m² | 1638400 per m² | 1137778 per m² | 640000 per m² |
| Module Resolution (WxH) | 240 x 270 | 192 x 216 | 160 x 180 | 120 x 135 |
| Brightness, max. (cd/m²) | 1000 nits | 1200 nits | 1600 nits | 800 nits |
| Refresh Rate (Hz) | 3840 Hz | 3840 Hz | 3840 Hz | 3840 Hz |
| LED Type | MicroLED 4-in-1 | MicroLED 4-in-1 | MicroLED 4-in-1 | SMD RGB |
| Frame Rate (Hz) | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz |
